Automatic Tension control and Redeviation System for Corrugated machines

Corrugated Machine - Automatic Web Paper Guide Device

Product Description

Speed: 150m/min - 400m/min

Control: Servo Control

High Precision, Reduce Waste Edge

Alignment accuracy: +/-1.5mm

Alignment arrangement: +/-60mm

Detect method: Digital infraid sensor

Applied speed: Max.350M/Min

Width: different width

Bridge guider

The fixed positioning of the single face webs with adjustable side plates causes frequently damages of the web edges and web tear outs. Unnecessary machine stops and an increased loss of material are the consequences.

The single face web can be guided alternatively in reference to the outer liner web. Full-width sensor also record the outer liner in her position, and, if desired, guide her to the machine center by using the BGM.

Production improvements:

- Even stable and vibration free entering of the webs into the double backer

- None deformation of the flute

- Can handling with different working widths could operated without any loss of time

- Improved heat transfer at the pre-heater through constant web tension

- Reducing the web demolition

- Increased average speed

- Minimizing machine down times through better lamination at the double backer and the slitter

Scorer

- Scanning of the single face webs without contact (also for the bottom liner)

- Stress free web alignment through laid on non crash (polyurethane) rolls

- High accuracy of web alignment

- Manuel adjustments to the new paper width are not longer necessary

- Continuous production through continuous operation of the controller

- Complete, compact and wired mounting frame

- Low maintenance through scavenging air blower for the scanning systems

- Improved service through use of Modem line
